ASUS ROG STRIX B760-F GAMING WIFI

Motherboard Specification

Processor Support:

Intel® Socket LGA1700 for Intel® Core™ 14th, 13th, and 12th Gen Processors

Chipset:

Intel® Z790

Memory Support:

4 x DIMM slots, max. 192GB, DDR5

Supports XMP and AEMP II

Graphics Ports:

1 x HDMI (4K@60Hz)

2 x Thunderbolt™ 4 (USB Type-C®)

Expansion Slots:

2 x PCIe 5.0 x16

1 x PCIe 4.0 x4

Storage:

5 x M.2 slots

4 x SATA 6Gb/s ports

Ethernet:

1 x Realtek 5Gb Ethernet

ASUS LANGuard

Wireless & Bluetooth:

Intel® Wi-Fi 7 (802.11be)

Bluetooth® v5.4

USB:

Rear USB (12 ports):

2 x Thunderbolt™ 4 (USB Type-C®)

6 x USB 10Gbps (5 x Type-A, 1 x Type-C®)

4 x USB 5Gbps (Type-A)

Front USB (9 ports):

1 x USB 20Gbps (Type-C® with up to 60W PD/QC4+)

2 x USB 5Gbps headers (4 ports)

2 x USB 2.0 headers (4 ports)

Audio:

ROG SupremeFX 7.1 Surround Sound

ESS® ES9218 QUAD DAC

Internal I/O Connectors:

1 x 24-pin main power connector

2 x 8-pin +12V power connectors

1 x 8-pin PCIe power connector

5 x M.2 slots

4 x SATA 6Gb/s ports

1 x USB 20Gbps (Type-C®)

2 x USB 5Gbps headers (4 ports)
